Hobbywing XERUN XR10 Pro Black G3

The XERUN XR10 Pro Black G3 ESC is designed for high-performance modified racing, offering smooth power delivery and advanced features that enhance your control on the track.



Key Features

  • Designed for Modified Racing: The ESC is optimized for modified racing, making it perfect for serious racers.
  • Polarity Protection: Built-in polarity protection helps safeguard your ESC. However, for complete reverse voltage protection, it's recommended to use a non-polarity capacitor.



Data Logging Function

The built-in data recording module can store up to 380 minutes of data, with 19 sessions of 20-minute recordings. This helps you keep track of your performance and make adjustments for the next race.



Freewheeling for Better Temperature Control

The freewheeling feature improves operational efficiency and helps reduce ESC temperature by around 15°C compared to the previous version, providing consistent performance even under high load.



Disc Brake Mode for Enhanced Control

With disc brake mode, braking feels smoother and more linear, allowing for better control, especially in corners. You can also fine-tune the brake response with the Brake Force Curvature setting.



Smart Fan Start-Stop Function

The fan automatically turns on when needed, helping the ESC stay cool while minimizing unnecessary power consumption and noise. You can also turn off this function through the ESC's settings.



Durable Frameless Fan

Made from special materials, the fan is more rigid and durable, enhancing the overall reliability of the ESC.



Dual Parameter Settings

With 24 basic parameters and 44 advanced settings, you can easily customize the ESC to suit your driving style. This gives you the flexibility to simplify tuning or dive deep into advanced configurations.



Low Center of Gravity Design

The improved, lower center of gravity makes this ESC perfect for on-road and off-road applications. The overall height has been reduced by 2mm, helping with vehicle balance.



Built-In BEC

The adjustable BEC supports high-voltage servos, with an output current of up to 10A and voltage adjustable from 5.0V to 7.4V. This ensures your servos perform optimally under any condition.



Reverse Polarity Protection

The standard version of the XR10 Pro G3 includes reverse polarity protection, preventing damage to the ESC from incorrect wiring. Note that the G3X version does not have this protection, so extra care is needed.



Applications

  • Suitable for 1/10th touring cars, buggies, drift cars, F1, and rally vehicles.



Choose Your Version

  • G3 (Black): Includes 13AWG wires and reverse polarity protection.
  • G3X (Titanium Gray): Includes 12AWG wires but does not offer reverse polarity protection.

**Note: For optimal performance and safety, carefully read the ESC manual and ensure correct settings before use.**



Product Specifications

  • Continuous/Peak Current: 160A / 1200A
  • Input Voltage: 2S LiPo
  • BEC Output: 5V-7.4V @6A (adjustable)
  • Dimensions: 35.0 x 33.6 x 30.3mm
  • Weight: 93g (G3), 101.5g (G3X)
