The incredible performance of the SP5 starts at the heart of the motor--the stator

Reedy's all-new Sonic SP5 stock motors feature an all-new and unique design, incorporating many features that will put it at the top of the pyramid when it comes to stock motor performance.

The incredible performance of the SP5 starts at the heart of the motor--the stator. Designed in-house, the stator's profile is intended to achieve maximum torque and power output without sacrificing RPM. High-quality copper magnet wire, sized to the maximum that the rules allow and wound with care to keep resistance near the legal minimum, is treated with heat transfer epoxy to dissipate heat and reduce internal temperatures resulting in less fade over the course of the race. An oversized collector ring not only dissipates heat, but in conjunction with thick solder tabs, reduces resistance and power loss.

A balanced rotor features a high-strength magnet that takes full advantage of dimensional rules to produce fade-free power with maximum effectiveness. The rotor is supported by precision stainless steel ball bearings to accommodate high RPM loads with exceptional efficiency and reliability. Like all Reedy Sonic motors, a high-quality sensor board rounds out the motor's interior.

Externally, the SP5 utilizes a lightweight two-piece CNC machined aluminum housing with an aluminum endcap and timing adjustability to accommodate fine-tuning for specific applications. This lightweight package is a welcome way to improve vehicle handling while improving chassis tuning flexibility.

Features:

• CNC-machined housing with optimized air cooling
• Custom high-power stator design
• Low-resistance solder tabs and collector ring
• Balanced rotor with high-strength magnet
• Dual precision ball bearings
• Aluminum end cap with adjustable timing
• Completely rebuildable
• Competition proven
• ROAR Approved

Parts List

1. Part #: 27486 - Sonic 540-SP5 Sensor Board
2. Part #: 27487 - Sonic 540-SP5 Motor Screw Set
3. Part #: 27483 - Sonic 540-SP5 Rotor, 12.5 x 7.15 x 25.8mm
4. Part #: 27484 - Sonic 540-SP5 Rotor, 12.3 x 7.15 x 25.8mm
5. Part #: 27476 - Sonic 540-SP5 Titanium Motor Screw Set
6. Part #: 27456 - 540-M4 Ball Bearing Set
7. Part #: 27457 - Reedy HV 30mm Aluminum Motor Fan
8. Part #: 27458 - Reedy HV 40mm Aluminum Motor Fan
9. Part #: 27423 - Reedy HV Motor Fan, with 195 mm extension
10. Part #: 994 - Flat Sensor Wire 125 mm/4.92 in, B5
11. Part #: 995 - Flat Sensor Wire 175 mm/6.89 in, B5M
12. Part #: 978 - Flat Sensor Wire, 70 mm/2.76 in
13. Part #: 979 - Flat Sensor Wire, 110 mm/4.33 in
14. Part #: 980 - Flat Sensor Wire, 150 mm/5.91 in
15. Part #: 981 - Flat Sensor Wire 200 mm
16. Part #: 982 - Flat Sensor Wire 270 mm/10.63 in

What is the SP5 motor, and what sets it apart from other stock motors?

The SP5 is an all-new stock motor by Reedy, featuring a unique design with several performance-enhancing features that distinguish it from other stock motors.

What is the significance of the stator in the SP5 motor?

The stator is at the heart of the SP5 motor's incredible performance. It is designed to maximize torque and power output without sacrificing RPM.

What kind of wire is used for winding the stator, and how is it treated?

High-quality copper magnet wire is used for winding the stator, and it is treated with heat transfer epoxy to dissipate heat and reduce internal temperatures, resulting in less power fade during races.

How does the rotor contribute to the motor's performance?

The rotor has a high-strength magnet that produces fade-free power effectively, and it is supported by precision stainless steel ball bearings for high RPM loads with efficiency and reliability.

What are some external features of the SP5 motor?

Externally, the SP5 has a lightweight two-piece CNC machined aluminum housing, an aluminum endcap, and timing adjustability for fine-tuning specific applications.

Are there any specific technical specifications for the SP5 motor?

Yes, the motor is ROAR Approved and designed for 1-2S LiPo cells. It has a diameter of 35.9mm, a length of 52.5mm, a shaft diameter of 3.15mm, and a weight range of 147-151 grams, depending on configuration. The stock rotor is #27483.

Can the SP5 motor be customized or rebuilt?

Yes, the motor is completely rebuildable, and it features low-resistance solder tabs and a collector ring for customization.

What are some compatible parts and accessories for the SP5 motor?

Compatible parts and accessories include the Sonic 540-SP5 Sensor Board, Sonic 540-SP5 Motor Screw Set, various rotor options, motor screw sets, ball bearing sets, and aluminum motor fans of different sizes.

What is the purpose of adjustable timing in the SP5 motor?

Adjustable timing allows users to fine-tune the motor's performance to suit specific applications and racing conditions.

Is the SP5 motor widely used in competitions, and is it considered a high-performance option?

Yes, the motor is competition proven and known for its high performance, making it a popular choice among racers.
